GC SPEC #06/A138
GC ITEM NUMBER
CABLE: 4 CORE 6MMSQ+2.5MMSQ EARTH PAC CONDUCTOR XLPE INSULATED
LAID UP, PVC BEDDING, SWA, PVC SHEATH
STANDARD: GENERALLY TO IEC60502-1 1998
600/1000 VOLTS
CONDUCTOR:PLAIN ANNEALED COPPER
STRANDING:7/1.04MM
SHAPE:CIRCULAR COMPRESSED
CSA 6MM²
DIA/DEPTH (MM): 3.06 MIN
3.06 NOM
3.06 MAX
INSULATION:AC SPARK TEST TO 6KV
EXTRUDED : XLPE COMPOUND TYPE OR EQUIVALENT
COLOURS: RED, WHITE (NAT), BLUE, BLACK
RADIAL: MIN AV 0.70MM
MAX AV 0.77MM
MIN PT 0.53MM
DIA/DEPTH (MM): 4.46 MIN
4.53 NOM
4.60 MAX
EARTH CONDUCTOR: PLAIN ANNEALED COPPER
STRANDING: 7/0.67
SHAPE : CIRCULAR COMPRESSED
C.S.A : 2.50MMSQ
INSULATION:AC SPARK TEST TO 6KV
EXTRUDED : XLPE COMPOUND TYPE OR EQUIVALENT
COLOURS: GREEN/YELLOW
RADIAL: MIN AV 0.60
MAX AV 0.66
MIN PT 0.44
DIA/DEPTH (MM) : 3.17 MIN
3.23 NOM
3.29 MAX
LAY UP: CORES LAID UP TO A CIRCULAR CONSTRUCTION
4 CORE + E STAGE
DIA/DEPTH (MM) : 12.14 MIN
12.34 NOM
12.54 MAX
BEDDING: EXTRUDED VD26 COMPOUND TYPE OR EQUIVALENT
COLOUR: BLACK
RADIAL (MM): MIN AV 1.00
MAX AV 1.10
MIN PT 0.60
DIA/DEPTH (MM): 14.14 MIN
14.44 NOM
14.74 MAX
ARMOUR:GALVANISD STEEL WIRE L/H LAY DIRECTION
# OF WIRES 36
RADIAL (MM) : 1.25
DIA/DEPTH (MM): 16.64 MIN
16.94 NOM
17.24 MAX
SHEATH: EXTRUDED VD26 COMPOUND TYPE OR EQUIVALENT
COLOUR: GREY(OR AS REQUESTED) WITH UV STABILISER
RADIAL (MM): MIN AV 1.80
MAX AV 1.98
MIN PT 1.24
DIA/DEPTH (MM): 20.24 MIN
20.72 NOM
21.20 MAX
|
IDENTIFICATION: SHEATH EMBOSSED/PRINTED:
(MANUFACTURERS NAME) X-90 ELECTRIC CABLE 600/1000 VOLT
6MMSQ CU 4C+EARTH (YEAR OF MANUFACTURE)
INTERVAL EVERY 500MM
PLUS SEQUENTIAL MARKING WITH ZERO AT DRUM END OF CABLE
TESTING: TEST TO IEC60502
INSULATION RESISTANCE TO BE RECORDED
TEST CERTIFICATE REQURIED
NOTE:MANUFACTURING TOLERANCES MAY ALLOW
PRODUCT DIMENSIONS TO LIE OUTSIDE ABOVE QUOTED VALUES
MODIFICATIONS:
06/11/06 ORIGINAL LB(GC)
|
