CABLE, STEEL WIRE ARMOURED, XLPE INSULATED
LAID UP, PVC BEDDING, SWA, PVC SHEATH
STANDARDS : CABLE MADE TO IEC60502-1 LV,
COMPLIANT WITH IEC60332-3-24
FLAME RETARDANT PROPERTIES
VOLTS : 600/1000
CONDUCTOR : TINNED ANNEALED STRANDED COPPER
STRANDING : 7/0.67MM
SHAPE : CIRCULAR SHAPE
CSA : 2.5MM²
DIA : 2.01MM NOM
INSULATION : EXTRUDED XLPE
COLOUR : RED, BLACK, YELLOW/GREEN
RADIAL : MIN AV 0.70MM
: MAX AV 0.77MM
DIA : MIN 3.41MM
: MAX 3.55MM
LAY UP : 3 CORE CIRCULAR, R/H LAY
BINDER : NOT REQUIRED
BEDDING : EXTRUDED PVC COMPOUND
COLOUR : BLACK
DIA : MIN 8.95MM
: MAX 9.41MM
COPPER EARTH SCREEN : PLAIN ANNEALED COPPER
WIRE SIZE : 0.67MM
NUMBER OF WIRES : 5
WIRES SPACED EQUALLY AROUND CABLE LAID LONGITUDINALLY AT LEAD EXTRUDER
LEAD SHEATH : EXTRUDED LEAD ALLOY 2 X RIPCORDS LAID UNDER SHEATH
RADIAL : MIN 1.30MM
: MAX 1.43MM
DIA : MIN 12.89MM
: MAX 13.61MM
BEDDING:EXTRUDED PVC COMPOUND
COLOUR : BLACK
RADIAL : MIN AV 1.20MM
: MAX AV 1.32MM
DIA : MIN 15.29MM
: MAX 16.25MM
ARMOUR:GALVANISED STEEL WIRE, L/H LAY, DIA 1.25MM
NUMBER OF WIRES : 39
DIA : MIN 17.79MM
: MAX 18.75MM
SHEATH : EXTRUDED PVC COMPOUND
COLOUR : GREY
RADIAL : MIN AV 2.00MM
: MAX AV 2.20MM
DIA : MIN 21.79MM
: MAX 23.15
|
